SPECIAL
FEATURES : |
| |
| - A
Pleasing design and perfectly smooth running of the machine. |
| - The main
frame of the machine is thick walled single piece construction, which
provides sturdiness and massive stability to the machine. |
| - Table of
the machine is of high grade casting suitably ribbed to maintain a
perfectly flat table surface even after years of use. |
| - Heavy
duty fence with dust chute is provided on the machine. |
| - A
dynamically balanced spindle running at high speed. |
| - Raising
and Lowering of spindle by means of hand wheel in front of the machine and
can be locked at any position. |
| - Machine
provided with spindle lock. |
| -
Emergency Stop provided in front of the machine. |
| -
Automatic Feeding Device fitted on the Table of the machine |
|
|
TECHNICAL SPECIFICATIONS |
|
|
| |
|
|
| * Working Table |
: |
1000 x 800mm |
| * Dimension of Spindle
|
: |
35mm |
| * Dimension of spring
catch |
: |
12.7 mm (1/2’) |
| * Spindle
Rotation |
: |
3000 / 4000 / 6000 /
8000 /
10,000 RPM |
| * Motor Power |
: |
5.5 KW |
| * Net Weight |
: |
370 KG |
| * Overall Dimensions (LxWxH)
|
: |
1100 x 1000 x 1100mm |
| |
|
|
