SPECIAL FEATURES : |
|
- A highly efficient, robust and precision machine. |
|
- Table is provided with two rollers for smooth feeding of the stock and has
rise and fall arrangement. |
|
- Cutter block is made of special alloy steel, ground and dynamically
balanced. It has a speed of 6000 r p m andcarries four knives to provide
excellent finish. |
|
- Feed and Discharge pressure guides the timber in the immediate vicinity of
the cutter head. |
|
- A sturdy backlash safety feature is incorporated in the machine. |
| |
|
TECHNICAL SPECIFICATIONS : |
| * Maximum
Planning Width |
: |
500mm |
| * Maximum
Thickness of workpiece |
: |
160mm |
| * Maximum
Planning Depth |
: |
6mm |
| * Minimum
Length of Planning |
: |
200mm |
| * Diameter of
Tool Bar |
: |
73mm |
| * Motor Power |
: |
4 KW |
| * Spindle
Speed |
: |
5000 RPM |
| * Feeding
Speed |
: |
7 M/Min |
| * Machine
Dimension |
: |
810mm x 745mm
x 1100mm |
| * Machine
Weight |
: |
430 KG |
| |
|
|
|
STANDARD ACCESSORIES SUPPLIED WITH THE
MACHINE : |
| - Planer
Blades |
: |
4 Nos.
(fitted on the machine) |
| - V-Belts
|
: |
1 Set (fitted
on the machine) |
| - Appropriate
sizes spanners |
: |
1 Set
|
| - Appropriate
sizes Allen Keys |
: |
1 Set |
| - Grease Gun
. |
: |
1 No |
| |
