Sandeep Machines Pvt. Ltd

‘SANDEEP’ CURVILINEAR EDGEBANDING MACHINE MODEL SCE50

SANDEEP SCE50 is a Manual Multi-Functional Curvilinear Edge Banding Machine and is for attaching Veneer, Melamine, PVC and ABS Edge Banding tape of size 0.4 to 3 mm thick/Solid Wood upto 4mm in Strips on Straight, Round or Curved Panels with Pre-heated glue at desired set temperature.

Glue Rollers are suitable for Panels Thickness from 10 to 50mm. Glue temperature control is in built in the machine. Electro-Pneumatic cutting device is provided & is fully covered by a guard for safety of the operator.

The Machines dispenses glue on the Tape as well as the Panel and the glue quantity can be adjusted. Machine works though a Foot Switches for Cutting the Edge Band on curvilinear mode and on straight mode it operates through a Limit Switch which is fitted on the fence of the table.

SALIENT FEATURES:
	Teflon Coated Glue Pot keeps the glue clean.
	Infinitely variable Feeding Speed with SERVO DRIVE.
	Pre-Selected Length Stop with Auto Tape Cutter.
	Machine Capable to use high temperature glue up to 200°C.
	Caster’s with lock are provided on the base of the machine for easy handling of the machine (ON REQUEST)
	Hot Air Gun is provided for pre-heating of the Tape (optional)
	Big Size Tape stand of Diameter 750mm to take big Edge Band Rolls.
	FRL fitted on the machine for clean and lubricated AIR SUPPLY.

TECHNICAL SPECIFICATIONS:

Edging Width		10~50mm
Edging Thickness		0.4~3mm
Min. Working Radius		30mm
Heating Power (5 Elements)		1.75KW
Edging Feeding Speed :		1~12m/min
Pneumatic Pressure :		≥4~5 KG/cm2
Motor Power :		0.2 KW
Electric power :		220 Volts Single Phase
Net Weight :		270 KG
Overall Dimensions		(LxWxH) : 1850 x 1150 x 1000mm

STANDARD ACCESSORIES • Instruction Manual • Tool box with required tools and spanners • Glue for first filling.
